Getting gcode errors openbuild control

Discussion in 'CAM' started by William Harper, Sep 5, 2019.

  1. William Harper

    William Harper New
    Builder

    Joined:
    Jan 30, 2017
    Messages:
    38
    Likes Received:
    5
    I'm using Dmap2gcode to generate 3d gcode from a grayscale emiage. when I start the project in openbuild control I get a error code 20. What do I need to get it running? I have attached the file.


    Attached Files:

    #1 William Harper, Sep 5, 2019
  2. sharmstr

    sharmstr OpenBuilds Team
    Staff Member Moderator Builder Resident Builder

    Joined:
    Mar 23, 2018
    Messages:
    2,059
    Likes Received:
    1,449
    G64 isnt supported. Change your first line from

    Code:
    G17 G90 G64 P0.001 M3 S3000
    To

    Code:
    G17 G90 M3 S3000
    I'm not familar with Dmap2gcode so there might be other issues I dont see. Basically you need a post processor that supports grbl: gnea/grbl

    #2 sharmstr, Sep 5, 2019
    Peter Van Der Walt likes this.
  3. sharmstr

    sharmstr OpenBuilds Team
    Staff Member Moderator Builder Resident Builder

    Joined:
    Mar 23, 2018
    Messages:
    2,059
    Likes Received:
    1,449
    I just installed it. If you go into settings, you can change the header so it doesnt output the G54 P0.001 codes.

    #3 sharmstr, Sep 5, 2019
    David the swarfer and Peter Van Der Walt like this.
  4. William Harper

    William Harper New
    Builder

    Joined:
    Jan 30, 2017
    Messages:
    38
    Likes Received:
    5
    thanks shaker I will give it a shot.

    #4 William Harper, Sep 5, 2019
    sharmstr likes this.
  5. William Harper

    William Harper New
    Builder

    Joined:
    Jan 30, 2017
    Messages:
    38
    Likes Received:
    5
    shaker your right all it took was to change the header. Working great now. Two thumbs up for you.

    #5 William Harper, Sep 6, 2019
    sharmstr likes this.
  6. sharmstr

    sharmstr OpenBuilds Team
    Staff Member Moderator Builder Resident Builder

    Joined:
    Mar 23, 2018
    Messages:
    2,059
    Likes Received:
    1,449
    Awesome!

    [​IMG]

    (2 shakers, one sharmstr)

    #6 sharmstr, Sep 6, 2019
    Alex Chambers, MaryD and Peter Van Der Walt like this.
  7. phil from seattle

    phil from seattle Journeyman
    Builder

    Joined:
    Mar 17, 2017
    Messages:
    315
    Likes Received:
    138
    I bet those drinks are well mixed!

    On the original point, some controllers throw an error and allow you to press go to continue - Grbl Panel, for example.

    Also, DMap2gcode has common code with F-Engrave which has the same issue.

    #7 phil from seattle, Sep 6, 2019
    sharmstr likes this.
  8. sharmstr

    sharmstr OpenBuilds Team
    Staff Member Moderator Builder Resident Builder

    Joined:
    Mar 23, 2018
    Messages:
    2,059
    Likes Received:
    1,449
    I think some allow you to even ignore them.

    #8 sharmstr, Sep 6, 2019
