OpenBuilds MiniMill

Discussion in 'CNC Mills/Routers' started by Mark Carew, May 26, 2017.

  1. Mark Carew

    Mark Carew OpenBuilds Team
    Staff Member Moderator Builder Resident Builder

    Joined:
    Jun 28, 2013
    Messages:
    2,759
    Likes Received:
    2,443
    Hey guys :)
    A quick heads up to let you know that the MiniMill videos have been updated to show the all new Build as well as the new super clean wiring with the all new OpenBuilds limit switches installed! Props go out to @Matthew Bates for the awesome job on the videos.
    Thank you

  2. Mark Carew

    Mark Carew OpenBuilds Team
    Staff Member Moderator Builder Resident Builder

    Joined:
    Jun 28, 2013
    Messages:
    2,759
    Likes Received:
    2,443
    New update: Added Z touch probe to the additional video section :)

  3. Alex Chambers

    Alex Chambers Master
    Moderator Builder

    Joined:
    Nov 1, 2018
    Messages:
    2,791
    Likes Received:
    1,369
  4. Lofton Harris

    Builder

    Joined:
    May 27, 2017
    Messages:
    8
    Likes Received:
    2
    Hey, Mark, where do I find the updated MiniMill video (wiring and touch probe)?

  5. Peter Van Der Walt

    Peter Van Der Walt OpenBuilds Team
    Staff Member Moderator Builder Resident Builder

    Joined:
    Mar 1, 2017
    Messages:
    15,123
    Likes Received:
    4,329
    Click the Build tab above (ie the MiniMill Build Page), scroll down to the Videos section. Good luck!



  6. Lofton Harris

    Builder

    Joined:
    May 27, 2017
    Messages:
    8
    Likes Received:
    2
    Thanks! Found it.

    Peter Van Der Walt likes this.
  7. Bruce H

    Bruce H New
    Builder

    Joined:
    Jun 17, 2014
    Messages:
    8
    Likes Received:
    3
    What's the minimum amps required from a 24V power supply to run the mini mill with the hi torque nema 23 motors?

  8. Peter Van Der Walt

    Peter Van Der Walt OpenBuilds Team
    Staff Member Moderator Builder Resident Builder

    Joined:
    Mar 1, 2017
    Messages:
    15,123
    Likes Received:
    4,329
    We recommend 24V Meanwell Power Supply Bundle

    MaryD likes this.
  9. Tbear1123

    Tbear1123 New
    Builder

    Joined:
    Sep 20, 2019
    Messages:
    19
    Likes Received:
    3

    Where did you buy this vise?

  10. Inge

    Inge New
    Builder

    Joined:
    Jun 9, 2019
    Messages:
    3
    Likes Received:
    0
    Is it possible to have this machine with worksize 200x200mm or 250x200mm?

  11. Bruce H

    Bruce H New
    Builder

    Joined:
    Jun 17, 2014
    Messages:
    8
    Likes Received:
    3
    It's only limited by your imagination. You can find other threads here of people who have customized their mini mills. Probably one of the most popular is Scotty Orr's mini mill XL conversion. It gives you a work area much larger than the stock mini mill. MMXL - A MiniMill Conversion

    Scotty Orr and Rick 2.0 like this.
  12. Inge

    Inge New
    Builder

    Joined:
    Jun 9, 2019
    Messages:
    3
    Likes Received:
    0
    Thanks :D

    EDIT:
    just checked the link..it will be too much work...since my skills are rather low :D haha
    ANyway..but it must be possible just to extend X and Y axis a bit?
    In my head I just need to get longer 8mm Metric lead screws and C-Beam Rails. All other parts will fit :D Extends this by a inch or 2 then it will cover my needs :D

    is this correct ? or I am way off ? TIA

    #312 Inge, Jan 4, 2020
    Last edited: Jan 4, 2020
  13. Rick 2.0

    Rick 2.0 OpenBuilds Team
    Staff Member Moderator Builder Resident Builder

    Joined:
    Dec 20, 2013
    Messages:
    2,896
    Likes Received:
    1,555
    X yes, Y no. X is as simple as ordering a 500mm C-beam and a matching screw. Y is limited by the throat depth between the router bit and the rear column. So making the axis longer really does nothing to increase the capacity. Increasing the throat depth by building out the upper assembly with some extra plates is possible but it leads to more flex in the rear column and thus reduces the quality of the output. When you start trying to stiffen the column, you realize you've created a monster...

  14. Inge

    Inge New
    Builder

    Joined:
    Jun 9, 2019
    Messages:
    3
    Likes Received:
    0
    Thanks for the informative feedback :D

  15. Sam Brenneman

    Builder

    Joined:
    Jan 24, 2020
    Messages:
    1
    Likes Received:
    3
    We tested my build, and found that the Z axis was not engaging the limit switch in time to prevent crashing. The solution was to attach a little pad of neoprene to the bracket, nice and clean, and that it that. It's my seventh machine build, the first six being some cranky and delicate robot arms. This was more fun, for sure. pad for mini mill.jpg

  16. Yanou Fishel

    Builder

    Joined:
    Dec 21, 2019
    Messages:
    35
    Likes Received:
    14
    Was just wondering, is it possible to use a smaller Z-plate to win some machining height? Perhaps something with wheels on the in- and outside to increase stiffness?

  17. Rick 2.0

    Rick 2.0 OpenBuilds Team
    Staff Member Moderator Builder Resident Builder

    Joined:
    Dec 20, 2013
    Messages:
    2,896
    Likes Received:
    1,555
    The Cbeam XL gantry plate is a fairly simple drop in. You also have a machine fully capable of machining whatever suits your needs. The only issue with the inside wheels is that they conflict with the lock collar on the lead screw which reduces usable distance.

  18. Yanou Fishel

    Builder

    Joined:
    Dec 21, 2019
    Messages:
    35
    Likes Received:
    14
    I've decided to add a Cbeam XL gantry plate :) Now for ordering and finishing up. I saw they're used on the LEAD, C-Beam,... machines, so it would seem to be stiff enough. Should also give me some more Z-working height without greatly reducing stiffness of the column

    Peter Van Der Walt likes this.
  19. Yanou Fishel

    Builder

    Joined:
    Dec 21, 2019
    Messages:
    35
    Likes Received:
    14
    Whilst building the minimill (or rather the enclosure it's going to sit in) after I've mounted the mill to a thick steel slab, I noticed one wheel on the Y-gantry plate seems out of allignment causing the whole X-axis to wobble about 0.5mm. Anyone know any (quick) solution for this? Not yet looking to get into linear rails as I'd like to cut the plates for them myself :)

    bagelmaker likes this.
  20. MatthewWeems

    Builder

    Joined:
    Apr 15, 2017
    Messages:
    4
    Likes Received:
    0
    Hello,

    Just wondering what happened to the firmware settings list for the minimill?

    It used to be posted on the product page.....

    Any help would be great.

    Please help,

    Matthew

    #320 MatthewWeems, Aug 19, 2020
    Last edited: Aug 19, 2020
  21. Peter Van Der Walt

    Peter Van Der Walt OpenBuilds Team
    Staff Member Moderator Builder Resident Builder

    Joined:
    Mar 1, 2017
    Messages:
    15,123
    Likes Received:
    4,329
    Openbuilds Control > grbl settings > select MiniMill from the drop down menu. Click save, click reset.

  22. Yanou Fishel

    Builder

    Joined:
    Dec 21, 2019
    Messages:
    35
    Likes Received:
    14
    It's still there under the "Spoiler: Standard Settings and Misc" button

    Peter Van Der Walt likes this.
  23. MatthewWeems

    Builder

    Joined:
    Apr 15, 2017
    Messages:
    4
    Likes Received:
    0
    Ok, thanks, hadn't gotten that far yet, I was planning on using Repetier firmware because I already have several ramps boards and I'm using as a 3dprinter. I'll download the app and get the settings. Thanks, Matthew

  24. VanAcker

    VanAcker New
    Builder

    Joined:
    Nov 11, 2020
    Messages:
    1
    Likes Received:
    0
    I really need the machines assembly manual. Please help

  25. Peter Van Der Walt

    Peter Van Der Walt OpenBuilds Team
    Staff Member Moderator Builder Resident Builder

    Joined:
    Mar 1, 2017
    Messages:
    15,123
    Likes Received:
    4,329
    Go to OpenBuilds MiniMill
    Scroll down about halfway to "Video Build of the Minimill: Jump in and when you complete this easy step by step build-along video you will have an awesome 3 Axis CNC Mini Mill for your Desktop"
    Click the Play button on the video and follow along step by step

    MaryD and Mark Carew like this.
  26. Marcin Miszewski

    Builder

    Joined:
    Jan 6, 2022
    Messages:
    1
    Likes Received:
    1
    I almost finished my build of MiniMill with few tweaks made by me. Should be a little bit more solid. 0.8kw router with VFD a2. Box with electronic fully designed by me and 3d printed.


    Attached Files:

    David the swarfer likes this.
